Description
Silicone cable 20AWG – 100 conductors – 0.5 mm² – red
Current wires of 0.5mm² (20 AWG) in black soft flexible silicone insulation, which allows any bending and bending of the wire. Silicone cables allow operation at temperatures from -65°C to 200°C.
Very convenient to use flexible cable with a wide range of applications from electronics to modeling, in particular:
- electrical switchboards,
- electric motors,
- heating elements,
- lighting,
- ventilation and air conditioning systems,
- plastics processing,
- construction of generators and transformers,
- industrial electronics,
- models of airplanes, cars, ships,
- batteries,
- etc.
Product Features:
- Wire dimensions are given in US unit of measure „AWG”.
- Flexible insulation made of silicone.
- Temperature resistant cable insulation from -65°C to 200°C.
- Silicone coating does not harden at low temperature.
- Resistance to acids and alkalis, oxidants, oils, alcohols.
- Very convenient to use, have a wide range of applications in making electrical connections.
- Indispensable for connections in the model power system.
- Soft and resistant insulation and dense wire makes it easy to bend and lay the wires in the model.
Technical data:
- Cable color: red
- Longest stretch on the roll 400m
| Connector | 10 AWG | 12 AWG | 13 AWG | 14 AWG | 16 AWG | 18 AWG | 20 AWG | 22 AWG | 24 AWG | 26 AWG |
| Current max. (A) |
140.6 A |
88.4 A |
65 A |
55.6 A |
42 A |
22 A |
13.87 A |
8.73 A |
5A |
3.5A |
| Conductor diameter (mm2) |
5.3 |
3.4 |
2.5 |
2.07 |
1.27 |
0,75 |
0,50 |
0,33 |
0,20 |
0,14 |
| Outer diameter |
5.5mm |
4.5mm |
4.0mm |
3.5mm |
3.0mm |
2.3mm |
1.8mm |
1.7mm |
1.6mm |
1.5mm |
Included:
- 20AWG silicone wire in red – 1mb
