Description
Silicone cable 16AWG – 252 conductors – 1.3 mm2 – red – ABC-RC
Current wires of 1.3mm² (16 AWG) in red soft flexible silicone insulation, which allows the cable to be bent and kinked as desired. Silicone cables allow operation at temperatures from -65°C to 200°C.
Very convenient to use flexible cable with a wide range of applications from electronics to modeling, in particular:
- electrical switchboards,
- electric motors,
- heating elements,
- lighting,
- ventilation and air conditioning systems,
- plastics processing,
- construction of generators and transformers,
- industrial electronics,
- models of airplanes, cars, ships,
- batteries,
- etc.
Product features
- Wire dimensions are given in US unit of measure „AWG”.
- Flexible insulation made of silicone.
- Temperature resistant cable insulation from -65°C to 200°C.
- Silicone coating does not harden at low temperature.
- Resistance to acids and alkalis, oxidants, oils, alcohols.
- Very convenient to use, have a wide range of applications in making electrical connections.
- Indispensable for connections in the model power system.
- Soft and resistant insulation and dense wire makes it easy to bend and lay the wires in the model.
Technical data
- Cable color: red
- Longest stretch on the roll 200m
| Connector | 10AWG | 12 AWG | 13 AWG | 14 AWG | 16 AWG | 18 AWG | 20 AWG | 22 AWG | 24 AWG | 26 AWG |
| Current max. (A) | 140.6 A | 88.4 A | 65 A | 55.6 A | 42 A | 22 A | 13.87 A | 8.73 A | 5A | 3.5A |
| Conductor diameter (mm2) | 5.3 | 3.4 | 2.5 | 2.07 | 1.27 | 0,75 | 0,50 | 0,33 | 0,20 | 0,14 |
| Outer diameter | 5.5mm | 4.5mm | 4.0mm | 3.5mm | 3.0mm | 2.3mm | 1.8mm | 1.7mm | 1.6mm | 1.5mm |
Included
- 16AWG silicone wire in red – 1mb
