Description

DC-DC converter – MT3608 2A 4-28V – Step-Up – voltage booster

DC-DC converter that raises the input voltage (step-up) from 3-25V DC to a voltage of 4-28V DC.

• The pulsed inverter is built on the MT3608 chip.
• Pulsed DC-DC voltage converter.
• Step up converter to increase voltage.
• The voltage is continuously adjustable with a potentiometer from 4V to 28V.
• The maximum load depends on the voltage.
• The input voltage should not exceed the large input voltage.
• Peak current output does not exceed 2A.
• The module is characterized by high efficiency and easy operation.

Technical specifications of MT3608 2A inverter

• 3V-25V input power supply
• output voltage 4-28V
• maximum current of 2A at the input
• operating frequency 1.2MHz
• efficiency: 93%
• dimensions 37x17x8mm
