Description

Li-ion 4S 14V / 16V 5A charging module

Electronic circuit that works as a battery protection against over-discharge. This module will also reliably function as a charger for these batteries.

Allows you to build a safe battery pack that does not need to be charged with special chargers for li-ion batteries.

The 2-in-1 module was created to keep the cells in the best possible condition by not allowing them to overcharge as well as over-discharge. One module here replaces the charger and security module.

More information about BMS modules, their application and how they work HERE.

Product features

• Short circuit protection.
• Protection against overcharging.
• Over-discharge protection.
• Overcurrent protection.
• Can be used for a variety of lithium cells 3.7V.
• Compact size and lightweight.
• Ensure the security of the package.

Technical data

• Size: 35x35x3mm
• Overload voltage detection: 4.25-4.35V ± 0.05 V
• Over-discharge voltage detection: 2.5V-3.0V ± 0.05 V
• Operating current: 5A
• Maximum current: 10A (overcurrent protection)
• Operating temperature: -40 ~ 50 degrees
• Storage temperature: -40 ~ 80 degrees
• Resting current: pon. 30uA
• Internal resistance: pon. 100mΩ
• Lifetime: pow. 50,000 hours

Included

• Li-Ion cell charging and protection module – 4S – 16V – 5A – for 18650 cells – green board
