AMS1117 mini power module – 3.3V 800mA – Arduino

Description

Mini power module dedicated to electronic circuits requiring 3.3V power supply. Contact pinouts are compatible with typical contact boards with a 2.54mm raster.

The circuit additionally has filters on the input and output of the stabilizer, so that the voltage is constant and does not have any noise or interference.

Note that with a heavy load, the AMS can be damaged and internally make a short circuit between input and output!

Description of the AMS1117 power supply

• Specially designed two rows of holes for soldering pins – dimensions prepared for contact boards
• AMS1117 3.3V mini power module
• Output voltage: 3,3V
• Maks. output current: 800mA
• Input voltage: 4.75-12V – (input voltage must be more than output voltage (1V more)
• Power signaling: LED
• Module dimensions: 26×10 mm

Included

• AMS1117 mini power module – 3.3V 800mA – Arduino
